SIS – 1399


Positive pressure modules are designed to provide a clean area within a small enclosure or cell. These pressure module adopts the same Laminar

Air Flow Principle. It generate positive where the room is totally closed. It provides a source of Fresh Air in the Room.



Wooden / M.S. Duly Power Coated / Stainless Steel Body .

HEPA Filter, Pre-Filter, Blower (Motor Blower Assembly), U.V. Lamp, Operating Switch

High quality HEPA filter provides protection for the product (filtration efficiency of more

Efficiency of more than 99.97% at 0.3 micron.

Ultra-quiet noise level of not more than 65 dBA.

Static Pressure Manometer.

Air Velocity : 90 ± 20 FPM (Average)

Profilter: 10 microns

220V Single Phase, 50 Hz.



Standard Size:- 2’x2’ 3’x2’ 4’x2’ 6’x2’ 8’x2’



Temp. 5°C – 50°C ± 1°C

With all Above Specifications & Accessories.



INSIDE CHAMBER SIZE

MADE OF STAINLESS STEEL  No. of Trays

18”×18”×18” (450×450×450mm) 2

18”×18”×28” (450×450×700mm) 3

24”×24”×24” (605×605×605mm) 3

24”×24”×36” (605×605×900mm) 4



SIS – 1334

Rotates specimens in horizontal plane in ¾” circles, constructed of mild steel finished with stoved enamel point, Turned up edges and rubber sheeting on platform to prevent slipping of specimen containers, platform rigidly supported by steel legs for smooth and silent rotation, mounted on four rubber suction feet to prevent creeping. Models:-


(A) 12”×12” (4 Flask of  250 ml)

(B) 18”×18” (16 Flask of  250 ml)

(C) 24”×24” (25 Flask of  250 ml)

(D) 36”×36” (36 Flask of  250 ml)



OR Any Non Standard Size.



SIS – 1341


The apparatus consists of an evaporating flask by DC motor in a heating water bath. Vacuum Distillation of solvent at high and low temperature is achieved quickly and efficiently by use of a variable speed motor, which prevents foaming and bumping of the liquid (solvent)into the evaporating flask and also distillation under controlled atmosphere. The evaporating flask is pear shaped to give a large surface area of evaporation and is clamped to a glass duct, which goes large surface area of evaporation and is clamped to a glass duct, which goes through the drive unit and produced into the condenser. The condenser is fitted with standard joint at the top and the bottom for receiver flask the unit is fitted with quick action.


(A) Water Bath Thermostatic OR Digital temp. controller

(B)     Oil Free Vacuum Pump

(C)     Micro Attachment Set


Rotation speed 20-140 rpm.

Evaporating flasks 800ml

Temperature range (water bath) Max.100 °C

Temperature Accuracy ± 1 °C

Condensing surface 1200 cm2

Operating Voltage 230v;50Hz

Power consumption Max. 2000W
